Popis

IR LED: 26pcs 940nm black Lights, 10M
Power: 4pcs AA Batteries or DC 5V
Image Sensor: 3MP Color CMOS
Photo resolution: 12MP 4032*3024

You now may enjoy the excellences reflected on this series product. This 12MP HD digital camera was totally R&D by our diligent and smart engineers based on feedbacks and requirements from customers globally. May you also enjoy and adore this product as we do. And our company is always open-minded with willing to adopt creative ideas from you.
Besides all the functions you may experience from any other similar product. This digital camera is aimed to offer user the most easy to use experience with extraordinary features, like 120°FOV Lens, 26pcs IR LEDs, 0.8S trigger time, and 1 photo/s, up to 5 photos and 30S video file per trigger.
This digital camera is an ideal product for housing security, warehouse surveillance, and monitoring wild animals with its camouflage appearance and nice shape. It is convenient to install or fasten, could be used to take photographs and carry on video files.

a. Instant surveillance camera for home, office, construction site, and warehouse, etc
b. Motion-triggered infra-red night vision surveillance;
c. Animal observation and hunting;

Power Supply

Camera runs on 4pcs AA batteries or DC 5V power or 5V solar panel

PR100C-2 PR100C-3

PR100C-1

Note: Recommend to remove AA batteries when power adapter is used.

Specifications:

Image Sensor: 3MP Color CMOS
Photo resolution: 12MP 4032*3024
Video resolution: FHD 1920*1080P 25FPS
Trigger time: 0.8S
Work mode: Photo, Video, Photo+video
PIR angle: 110 degree
Lens: wide 120degree
IR LED: 26pcs 940nm black Lights, 10M
PIR Distance: 15M
Memory: Max Micro SD 32GB (not included)
USB Slot: 5pins USB 2.0
Power Supply: 4pcs AA Batteries or DC 5V
Waterproof: IP54
Stand-by Time: 12Months
Stand-by current: 0.01mA
Size: 135*90*55MM
Weight: 160g
Temperature: -10~+70℃/-14~+158℉
Certification: CE FCC ROHS

Set Date and Time:

Set up a text file as name: time, open “time.txt” file, set date and time format: 2019-11-11 12:59:59 332Y, and save it to Micro SD card root.

PR600-time settings

Note: change date, time and work mode, only change digital and letter, can not change format, and save time.txt file. Change date, time, work mode, must put the switch to off and cut off power (move out battery).

How to Use ?

A: Open battery box, and put 4pcs AA batteries to Camera
B: Insert Micro SD card to Camera (not included standard package)
C: Put the switch to “ON” position, and the indicator light will flashing 2 times to go out, Camera will enter PIR detect status.
D: It will take 3 photos and 10s video record when it has PIR detected
E: It will not take photo and video recorder when it doesn`t have PIR detect, it will enter standby status or shut off
F: It have Overwrite function
